Manufactured in-house to exacting tolerances, A/C ’s drive units are legendary for their many design innovations. Hand-wound, short voice coils use only high density edge wound, flat OFC wire and operate in precision long magnetic gaps. Front and rear magnetic venting not only reduces airflow noise, but increases power handling and long term reliability. Massive, motor assemblies offer no-compromise optimisation for each voice coil diameter.


Technical Specification

System type

3-way  4-speaker system

Bass drivers

2 x 7.2"

Midrange drivers  2.5"

Tweeter driver

1.2" Ribbon Tweeter driver

Impedance

6 ohms average

Crossover

3,500 Hz

Frequency response

180 ~ 25,000 Hz(±3dB)

Sensitivity

86dB / 2.83v / 1m

Recommended power

amplifiers from 100 to 200 watts

Dimensions (WxHxD)

510 x 200 x 270 mm

Weight per speaker

42 kg

Sticker price £11,600.00



-Speaker
